BSC Standard All-In-One

Product model : 135"

Product Type : GOB

Size(inch) : 135

Pixel Pitch(mm) : 1.5

Overall Dimension(mm) : 3030.8x1812.9x31'

Net weight(kg) : 110

Average power consumption(kw) : 0.483

Maximum power consumption(kw) : 1.46

Resolution : 1920x1080

Contrast : 15000:1

Grayscale : 13~16bit

Speaker unit : 4 full range units + 2 low frequency units

Speaker maximum power : 120w

Max. sound pressure level : 95dB

Audio frequency domain : 60Hz~20kHz

Refresh Rate : 3840Hz

Brightness : 100~600cd/㎡(Adjustable)

Viewing Angle(H/V) : 165°/165°

Input and output interface : Input：HDMI2.0 *1、HDMI1.4 *3、USB2.0 *1、USB3.0 *2、Type-C *1、POE *1、RJ45 *1、3.5mm Audio in *1、RS232 *1
Output：HDMI2.0 *1、3.5mm Audio out *2、USB *1

Operating system : Android13.0，8G + 64G，Cortex-A76 ×4 + Cortex-A55 ×4
Optional Windows System

Cabinet material : Die-casting magnalium

Installation method : Mobile Stand , Wall mounting, Ceiling-hanging

Contact Now

Integrated All-in-One Design

BSC Standard All-In-One

Easy Installation & Quick Setup

BSC Standard All-In-One

CustomizedSolutions Available

BSC Standard All-In-One

Technical Specifications

Product model	138"	168"	220"	135"	162"	216"
Product Type	SMD			GOB
Size(inch)	138	168	220	135	162	216
Pixel Pitch(mm)	1.5	1.9	1.2	1.5	0.9	1.2
Overall Dimension(mm)	3080x1840x28'	3690x2183x28'	4910x2869x28'	3030.8x1812.9x31'	3630.8x2150.4x31'	4830.8x2825.4x31'
Net weight(kg)	122	172	296	110	155	285
Average power	0.521	0.731	1.514	0.483	0.647	1.158
consumption(kw)
Maximum power	1.738	2.438	5.046	1.46	2.154	3.858
consumption(kw)
Resolution	1920x1080	1920x1080	3840x2160	1920x1080	3840x2160	3840x2160
Contrast	6500:01:00			15000:1
Grayscale	14bit			13~16bit
Speaker unit	4 full range units + 2 low frequency units
Speaker maximum power	120w
Max. sound pressure level	95dB
Audio frequency domain	60Hz~20kHz
Refresh Rate	3840Hz
Brightness	100~600cd/㎡(Adjustable)
Viewing Angle(H/V)	160°/140°			165°/165°
Input and output interface	Input:HDMI2.0 1,HDMI1.4 3,USB2.0 1,USB3.0 2,Type-C 1,POE 1,RJ45 1,3.5mm Audio in 1,RS232 *1
	Output:HDMI2.0 1,3.5mm Audio out 2,USB *1
Operating system	Android13.0,8G + 64G,Cortex-A76 ×4 + Cortex-A55 ×4
	Optional Windows System
Cabinet material	Die-casting magnalium
Installation method	Mobile Stand , Wall mounting, Ceiling-hanging
Maintenance method	Front-maintenance
Recommended viewing	≥3.2	≥3.8	≥5.0	≥3.2	≥1.9	≥2.5
distance(m)

Aging test

BSC Standard All-In-One

References 1

BSC Standard All-In-One

References 2

BSC Standard All-In-One

References 3

BSC Standard All-In-One

References 4

BSC Standard All-In-One
